Pressta Eisele 7000 - Corner Crimping Machine


Pressta Eisele 7000

Corner crimping machine Max profile height 250mm
Precisely equalised crimping pressure
Descending V block for easy loading
Self adjusting V block
Secure pneumatic clamping
Magnetic feeler for rapid adjustment
Adjustable support arms
Quick release tooling
Adjustable spread restrictors
Max profile height 250mm

Pressta 5000 Corner Crimping Machine

Precise joining of aluminium and steel profiles over internal cleats. Generally used in the production of aluminium windows & doors, internal partitioning, automotive and railway stock glazing, marine glazing, sign making and lighting products. This model is made for joining profiles up to 250mm in height.

<td style=”font-weight: 400;”>Max tool Height (crimping height)

<tr>Smallest inside frame dimension195mm

Max Profile Height=”font-weight: 400;” width=”141″>250mm
Max V block height125mm
Max number of tools per head3
Crimping point scope25mm – 60mm
Max profile width–mm
Crimping power per head64KN
Working height940mm
Foot print1250mm x 680 mm
