Pressta Eisele 5000
Precisely equalised crimping pressure
Descending V block for easy loading
Self adjusting V block
Secure pneumatic clamping
Magnetic feeder for rapid adjustment
Adjustable support arms
Quick release tooling
Adjustable spread restrictors
Max profile height 160mm
Scroll down for specification, optional extras, videos & more ⬇️
Pressta 5000 Corner Crimper
Precise joining of aluminium and steel profiles over internal cleats. Generally used in the production of aluminium windows & doors, internal partitioning, automotive and railway stock glazing, marine glazing, sign making and lighting products.
| Max Profile Height | 160mm |
| Max tool Height (crimping height) | 130/145mm |
| Max V block height | 120mm |
| Max number of tools per head | 3 |
| Crimping point scope | 25mm – 60mm |
| Max profile width | –mm |
| Smallest inside frame dimension | 110mm |
| Crimping power per head | 56KN |
| Working height | 950mm |
| Foot print | 1250mm x 680 mm |
| Weight | 260kg |
