Multi-Head Drill Machine for Linear Rails

Automated production cell for centreline pitch Drilling
Automated loading and unloading of material
28 position tool magazine
4 spindles with auto tool change
Capable of drilling round and square solids or tubes
Swarf management system
Watch the video in the tab below

NG Tech Multi-Head Drill Machine

Automated production cell for centreline pitch Drilling – Milling – Tapping – Counter bore – and Reaming of linear rail and other similar applications.

The work:
System designed for drilling, reaming, tapping and holes counterbore;
All processing occurs by means of four spindles with automatic tool change.

The machinable profiles are all kinds of linear rails with a series of holes in the middle pitch, or profiles of various types (round and square tubes, bars, in the drawing).

Excellent performance of production due to the simultaneous processing of four profiles (raw parts), the automatic locking and automatic loading / unloading

Specification Table
  • 28 seats tool magazine
  • N# 4 spindles
  • Spindle speed 5000 r/min
  • X axis speed 60 mt/min
  • Z axis speed 30 mt/min
  • S axis motor 7.5 kw
  • Clamping device with automated tightening with possibility to adjust the pressure and setable opening course
  • Automatic product cleaning
  • Automatic clamping device cleaning
