Mecal MC 316 Sawing & Machining Line
For Aluminium or PVC extrusions
4 spindle (option for 6) machining capability
Spindle frame rotation 180°
3 axis mitre saw with encoded rotation
3 axis gripper adjusts to any profile (optional rotation)
Automatic loading table
Unloading table with conveyor and storage zone
CAD/CAM 3d software
Mecal MC 316 Automated production cell
A technically advanced manufacturing cell (sawing & machining line) for aluminium and PVC windows and doors or similar extrusions. Consisting of a horizontal loading table with user definable partitions, usually dictated by the dimension of the largest profile. The processing unit contains a 3 axis sawing head and 4 spindle (option for 6) machining element with 180° rotation of the tool holding frame, there is an option for a material rotation axis on the gripper to add machining capability. There is no automatic tool change on machines of this design.
| Stock extrusion max length | mm | 7200 |
| Minimum stock length | mm | 1000 |
| Maximum combined loading width (qty capacity to be defined) | mm | 2200 |
| Gripper U axis feeding stroke | mm | 9530 |
| Gripper V axis horizontal adjustment | mm | 225 |
| Gripper W axis vertical adjustment | mm | 200 |
| Gripper (optional) C axis rotation | ° | 0° – 180° |
| Spindle quantity | 4 units (option for 6) | |
| Spindle power and speed | kw-rpm | 4.5 – 24000 |
| Tool holder (manual change) | ER | 32 |
| Machining capacity Width | mm | 250 |
| Machining capacity Height | mm | 150 |
| Sawblade diameter | mm | 550 |
| Sawblade motor power and speed | kw/rpm | 2.7 – 3000 |
| Sawblade rotation range | ° | 135 |
| Sawblade and cutting tool lubrication | Venturi mist | |
| Unloading table dimension | mm | 5000 x 1700 (Option for 7200 x 1700) |
| PC Desktop Windows 10 with MeSoft cad/cam – industry 4.0 ready |
