Everising H7050 Band saw

Semi auto twin column 90° cutting / 500mm capacity (round bar)
Column type down feed system
Hydraulic blade tension
Hydraulically clamped carbide blade guides
Hydraulic work lift roller
Manual ratchet feed
Split vice jaws for nib free cutting
Power driven wire brush
Infeed & outfeed roller conveyors
Idler wheel motion detector
blade stalling & breakage shut-off
Automatic saw frame return selector
Cutting fluid flushing hose for cleaning
Roller stock table 1M long

Everising H7050

Semi-Automatic bandsaw ideally suited for production cutting of large solid materials including heavy tubes and sections. These high quality sawing machines are well known for their longevity and build quality. Round cutting capacity is 500mm, square / rectangle 700x500mm.

H-7050
Capacity – Round Bar 500 mm
Capacity – Square 700 x 500 mm
Blade Speed 17, 25, 35, 45, 65, 75 m/min (55, 80, 115, 150, 180, 215, 250 fpm)
Blade Drive Motor 5.5 kW (7.5 HP)
Hydraulic Pump Motor 1.5 kW (2 HP)
Coolant Pump Motor 0.2 kW (1/4 HP)
Blade Size 5450 x 41 x 1.3mm (192″ x 1.6″ x 0.05″)
Blade Tension Hydraulic
Index Length
Machine Weight 2400 kgs
Floor Space (L x W) 2700 x 2000 mm
Everising vice pressure reducer

Vice pressure reduction valves with gauges for thin walled materials, the gauges help record the relevant pressure for repeated jobs.

Everising Inverter Variable Speed

Variable blade speed with inverter and digital display

Everising Swarf Remover

Hydraulic centreless swarf remover

Addimist Bandsaw

Pure oil micro-mist blade lubrication system recommended for cutting tubes and sectional material where flood lubricant loss through the material is a problem. This precision delivery system allows adjustment for the number of pulses per min, and the quantity of each dose. (requires compressed air supply) The standard flood system is retained for cutting solid material and the operator can simply switch between systems.

Additrack 2M

Roller support table 2000mm long with 350mm or 500mm wide rollers.
