CSM TMRE Push/Roll Mandrel Tube Bender
Servo Driven Bend Arm (C) Axis
Hydraulic clamp die
Hydraulic pressure die
(Y Axis) Carriage with servo motor
Collet (B Axis) rotation with servo motor & hydraullic
Servo tooling shift L/R and U/D
Automatic mandrel lubrication
Anticipated mandrel retraction
Remote control panel
User friendly touch screen HMI with 3D bending simulation
Unlimited number of job programs
Rear Boost for x 1D bending available
3D preview and collision prevention
CSM TMRE
The TMRE tube bending machine is a triple stack electrically & hydraulically controlled mandrel tube bender with three stack positions when 3D bending or rolling tubes and profiles.
The machine is supplied with servo driven B, C, X and Y axes (tube rotation, bending, a transverse shift of the bending head, and tube shift) whilst clamping elements and the vertical shift of the bending head (tool stack change) are driven hydraulically. An additional feature includes automatic mandrel lubrication. It is possible to fit the machine with three different bending tools or alternatively the bending tools and rollers for the rolling of larger radius sweeping bends. The machine is operated via a control panel with a touch display located on a portable stand. Software on a windows based industrial PC allows the entering of data for the complete bending cycle whilst saved data can be copied, edited and backed up using the USB connector for data transfer.
TMRE Specification
The following table displays information for each machine in the TMRE range.
| OD | WT | CLR | mandrel working distance | tooling capacity | roll bending | rear booster | CSM part no. |
| 25.4 | 1.5 | 15-120 | 1500 | 3 | yes | 25 TMRE | |
| 30 | 2 | 15-120 | 2200 | 3 | yes | 30 TMRE | |
| 38.1 | 1.8 | 25-150 | 2200 | 3 | yes | 38 TMRE | |
| 50.8 | 2 | 30-220 | 2500 | 3 | yes | 50 TMRE | |
| 65 | 2 | 35-250 | 2500 | 3 | yes | 65 TMRE | |
| 80 | 2.5 | 40-280 | 3500 | 3 | yes | 80 TMRE | |
| 100 | 3 | 30-300 | 3500 | 3 | yes | 100 TMRE | |
| 65 | 2.5 | 35-250 | 2500 | 3 | yes | servo | 65 TMRE-RBE |
| 80 | 2.8 | 40-280 | 3500 | 3 | yes | servo | 80 TMRE-RBE |
| 100 | 3.6 | 30-300 | 3500 | 3 | yes | servo | 100 TMRE-RBE |
For more information, click on the table to be taken to the manufacturer’s website
