Addison Jubilee VBS500 Bandsaw

General workshop vertical bandsaw
Variable blade speed with inverter
Rubber bonded band wheels
Tilting table for bevel cuts
LED Work light
Air blower to clear chips
Rip fence

Addison Jubilee VBS 500

Vertical variable speed bandsaw with stationary table and 510 mm throat. The VBS bandsaws are the UKs most popular choice offering proven performance and reliability and highly suitable for workshop applications.

Specification Table

Height Under Guides (MAX)319 mmThroat (Band to Column)500 mm
Blade Speed Range97-2100 f/min   29~640 m/minBlade Width Scope1/4″ ~ 3/4″
Blade Length4005 mm to 4050 mm  maxTable Dimensions595 mm x 547 mm
Table Tilt Range15°L – 45°R
Motor Power2hp 3phNet Weight600 kg
Shipping Weight700 kgMachine Dimensions1199 x 739 x 1959 mm
Dust extraction

Dust and swarf extraction systems, these are generally 2 point designs from close to the cutting area, and from the lower band wheel chamber. Both the extractor and points of extraction can be bespoke to work with a very wide range of materials.

Addimist Bandsaw

Pure oil micro-mist blade lubrication system recommended for cutting tubes and sectional material where flood lubricant loss through the material is a problem. This precision delivery system allows adjustment for the number of pulses per min, and the quantity of each dose. (requires compressed air supply) The standard flood system is retained for cutting solid material and the operator can simply switch between systems.
